RMS Open API #

This document description how RMS system can integration with 99 about gas station process.

Environment Description #

product domain: drvlab-api.didiglobal.com

test domain: drvlab-test.didiglobal.com

Note

please use https instead of http

Http Code Description #

For all APIs, if an error occurs, you should try the request three times.

Http Response Field Description #

Errno description #

When you receive errno 10012, you need to make a request retry. For other error codes, you can contact us.

Authentication Method #

Authentication Steps #

1. Contact 99 team, and send access configuration to them.
2. Use the api_secret to generate authentication signature.
3. Use the api_key and signature to request API.

Field Description #

Token assignment #

99 will assign a pair of api_key and api_secret for you, for example

{
  "api_key": "ZRFRHQWF",
  "api_secret": "HJBHMPNNISKGYGXP"
}

Signature rules #

the caller should construct the signature string according to the signature rules below, and 99 will use the same rule to validate the signature string.

The signature body should like this(please be careful about the \n at the tail of each line):

http request method\n
URL\n
timestamp\n
nonce_string\n
http request body\n
api_secret\n

more explain:

• http request method: the upper case of http request method, eg:GET,POST,PUT and so on.
• URL:the url of the http request,should contain the params after ?.
• timestamp:the current timestamp of the http request initiation,for example 1678104305
• nonce_string:the random string, used in signature body, for example:593BEC0C930BF1AFEB40B4A08C8FB242
• http request body: the request body,for GET request, it should be empty string.otherwise,it should be the json string of http request body.for golang,use json.Marshal, for java you can try gson.
• api_secret: signature secret key

Then performing SHA256 operation on the signature body , and converting the value to uppercase.

Signature step by step #

Step 1 Get the http method

GET

Step 2 Get the http url

/open/ping?param1=aaa&param2=bbb

Step 3 Generate current timestamp

1678329955

Step 4 Generate random string

Th08TQosfSFXygWhKvdg5dSE4Oi1rlqj

Step 5 Generate http body, for this GET request, it should be empty string.

Step 6 Append the api_secret

HJBHMPNNISKGYGXP

finally, the signature body should looks like this below:

GET\n
/open/ping?param1=aaa&param2=bbb\n
1678329955\n
Th08TQosfSFXygWhKvdg5dSE4Oi1rlqj\n
\n
HJBHMPNNISKGYGXP\n

Step 7 do SHA256 to the above signature body, we will get signature string like this:

A2CE09D789CB12167CD2B7B6FD99A2A73515CA05F01AC33377428AA2A1BD4E4F

Step 8 Set the http header like this

Authorization:auth_type|signature_info

auth_type: it should be DIDI-AUTH-SHA256 now.

signature_info: contains the json format information:

• api_key
• nonce_string
• timestamp
• signature value generate at Step 7

example:

Authorization:DIDI-AUTH-SHA256|{"api_key":"ZRFRHQWF","nonce_string":"Th08TQosfSFXygWhKvdg5dSE4Oi1rlqj","timestamp":"1678329955","signature":"A2CE09D789CB12167CD2B7B6FD99A2A73515CA05F01AC33377428AA2A1BD4E4F"}

Authentication Code Demo #

Take the above sample sign generation as an example, we provide the signature code demo in postman, golang and java.

Pre-request Script Demo in postman #

var crypto = require('crypto-js');
var apiKey = "your api key should be here";
var apiSecret = "your api secret should be here";

// get random string for signature
function getRandomString(length) {
    var nonceSymbols = "0123456789abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ";
    var symbolLen = nonceSymbols.length;
    var result = '';
    for (var i = length; i > 0; --i) {
        var radomIndex = Math.floor(Math.random() * symbolLen);
        result += nonceSymbols[radomIndex];
    }

    console.log("random string: " + result);
    return result;
}

// generate signature
function generateSignature(apiSecret, timestamp, nonceString) {
    var method = pm.request.method;
    var path = pm.request.url.getPath();
    var body = pm.request.body;

    var signatureFormat = method + '\n' + path + '\n' + timestamp + '\n' + nonceString + '\n' + body + '\n' + apiSecret + '\n';
    var signature = crypto.SHA256(signatureFormat);
    signature = signature.toString().toUpperCase();

    console.log('signatureFormat:\n' + signatureFormat);
    console.log('signature: ' + signature);
    return signature;
}

// generate authorization header
function generateHeader(apiKey, apiSecret) {
    var timestamp = parseInt(Date.now() / 1000);
    var nonceString = getRandomString(32);
    var signature = generateSignature(apiSecret, timestamp, nonceString);
    var header = 'DIDI-AUTH-SHA256|{"api_key":"' + apiKey + '","nonce_string":"' + nonceString + '","timestamp":"' + timestamp + '","signature":"' + signature + '"}';
    console.log("header: " + header);
    return header;
}

var aHeader = generateHeader(apiKey, apiSecret);

// add authorization header to reqeust
pm.request.headers.remove("Authorization");
pm.request.headers.add(
    {
        key: "Authorization",
        value: aHeader
    }
);

golang version #

package gist

import (
	"crypto/rand"
	"crypto/sha256"
	"encoding/hex"
	"fmt"
	"strings"
	"time"
)

const (
	NonceSymbols = "0123456789abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ"
	NonceLength  = 32
)

func GenerateNonce() (string, error) {
	bytes := make([]byte, NonceLength)
	_, err := rand.Read(bytes)
	if err != nil {
		return "", err
	}
	symbolsByteLength := byte(len(NonceSymbols))
	for i, b := range bytes {
		bytes[i] = NonceSymbols[b%symbolsByteLength]
	}
	return string(bytes), nil
}

func Signature() {
	apiKey := "ZRFRHQWF"
	httpMethod := "POST"
	url := "/open/rms/productSync"
	timestamp := time.Now().Unix()
	nonceString, _ := GenerateNonce() // you can use other random string method
	httpBody := `{"requestId": "41AFC51C446AD26","gasStationID": "T1704529600027","timestamp": 1701951308,"products": [{"productCode": "123","productDescription": "GASOLINA ADITIVADA","productType": "GASOLINA_ADITIVADA","status": "ATIVO","price": 5.28,"fuel": true,"ncm": "27101259","anp": "320102002"}]}`
	apiSecret := "HJBHMPNNISKGYGXP" //please replace i

	signatureFormat := fmt.Sprintf("%s\n%s\n%d\n%s\n%s\n%s\n", httpMethod, url, timestamp, nonceString, httpBody, apiSecret)
	fmt.Println(signatureFormat)

	h := sha256.New()
	h.Write([]byte(signatureFormat))
	signatureString := strings.ToUpper(hex.EncodeToString(h.Sum(nil)))
	fmt.Println(signatureString)

	authorization := fmt.Sprintf(`DIDI-AUTH-SHA256|{"api_key":"%s","nonce_string":"%s","timestamp":"%d","signature":"%s"}`,
		apiKey, nonceString, timestamp, signatureString)
	fmt.Println(authorization)
}

java version #

import com.google.gson.Gson;
import java.io.*;
import java.nio.charset.StandardCharsets;
import java.security.MessageDigest;
import java.security.NoSuchAlgorithmException;
import java.security.SecureRandom;
import java.util.ArrayList;
import java.util.List;

public class testClient {
    protected static final String SYMBOLS = "0123456789abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ";
    protected static final SecureRandom RANDOM = new SecureRandom();
    public static void main(String[] args) {
        // assume req is your request object
        RequestExample req = new RequestExample();
        req.setDriverID(23);
        req.setRequestID("first_request");
        List<OrderItem> l = new ArrayList<>();
        OrderItem order1 = new OrderItem(false,1);
        OrderItem order2 = new OrderItem(true,2);
        l.add(order1);
        l.add(order2);
        req.setList(l);
        testClient testClient = new testClient();

        // build sign-message and get signature
        String signature = testClient.signature(req);

        // signature to upper
        String toUpperCase = signature.toUpperCase();
        System.out.println(toUpperCase);
    }
    public String signature(Object request) {
        Gson gson = new GsonBuilder().disableHtmlEscaping().create();
        String requestString = gson.toJson(request);
        long timestamp = generateTimestamp();
        String nonceStr = generateNonceStr();
        String httpMethod = "POST";
        String url = "/open/rms/productSync";
        String apiSecret = "adsfasdfa";
        String message = buildMessage(requestString, timestamp, nonceStr, httpMethod, url, apiSecret);
        System.out.println(message);
        return getSha256Str(message);
    }
    public String buildMessage(String requestString, long timestamp, String nonceStr, String httpMethod,String url, String apiSecret)  {

        return httpMethod + "\n"
                + url + "\n"
                + timestamp + "\n"
                + nonceStr + "\n"
                + requestString + "\n"
                + apiSecret + "\n";
    }

    public String generateNonceStr() {
        char[] nonceChars = new char[32];
        for (int index = 0; index < nonceChars.length; ++index) {
            nonceChars[index] = SYMBOLS.charAt(RANDOM.nextInt(SYMBOLS.length()));
        }
        return new String(nonceChars);
    }

    public long generateTimestamp() {
        return System.currentTimeMillis() / 1000;
    }

    public String getSha256Str(String str) {
        MessageDigest messageDigest;
        String encodeStr = "";
        try {
            messageDigest = MessageDigest.getInstance("SHA-256");
            messageDigest.update(str.getBytes(StandardCharsets.UTF_8));
            encodeStr = byte2Hex(messageDigest.digest());
        } catch (NoSuchAlgorithmException e) {
            e.printStackTrace();
        }
        return encodeStr;
    }
    //byte->string
    public String byte2Hex(byte[] bytes) {
        StringBuilder stringBuilder = new StringBuilder();
        String temp;
        for (byte aByte : bytes) {
            temp = Integer.toHexString(aByte & 0xFF);
            if (temp.length() == 1) {

                stringBuilder.append("0");
            }
            stringBuilder.append(temp);
        }
        return stringBuilder.toString();
    }
}

class RequestExample {
    private String requestID;
    private long driverID;
    private List<OrderItem> list;

    public void setDriverID(long driverID) {
        this.driverID = driverID;
    }

    public void setList(List<OrderItem> list) {
        this.list = list;
    }

    public void setRequestID(String requestID) {
        this.requestID = requestID;
    }

    public long getDriverID() {
        return driverID;
    }

    public List<OrderItem> getList() {
        return list;
    }

    public String getRequestID() {
        return requestID;
    }
}

class OrderItem implements Serializable {
    private boolean cancel;
    private int transactionItem;
    public OrderItem(boolean cancel, int tansaciton){
        this.cancel = cancel;
        this.transactionItem = tansaciton;
    }
}

Data Flow #

1. The flow of product synchronization and price update.
2. The flow of "validate code --> payment --> cancel order"
3. The flow of "validate code --> cancel order"

Testing Scenarios #

When you finished the integration, you should simulate the following four scenarios and send trace_id of those request to 99 team. 99 team will confirm whether the integration is ok or not.

1. Scenario 1(confirm flow paymentMethod type is Pix): productSync --> validate driver discount code --> driver payment --> confirm the order

2. Scenario 2(confirm flow paymentMethod type is Pix): productSync --> validate driver discount code with two products --> driver payment --> confirm the order

3. Scenario 3(cancel flow paymentMethod type is Pix): productSync --> validate driver discount code --> driver payment --> cancel the order

4. Scenario 4(pre-cancel flow): productSync --> validate driver discount code --> cancel the order without payment

5. Scenario 5(confirm flow paymentMethod type is Dinheiro): productSync --> validate driver discount code --> driver payment --> confirm the order

6. Scenario 6(confirm flow paymentMethod type is Cartão de débito): productSync --> validate driver discount code --> driver payment --> confirm the order

7. Scenario 7(confirm flow paymentMethod type is Cartão de crédito): productSync --> validate driver discount code --> driver payment --> confirm the order

8. Scenario 8(confirm flow paymentMethod type is Carteiras digitais): productSync --> validate driver discount code --> driver payment --> confirm the order

9. Scenario 9(confirm flow paymentMethod type is Cheque): productSync --> validate driver discount code --> driver payment --> confirm the order

10. Scenario 10(confirm flow paymentMethod type is Cartão de débito and Cheque): productSync --> validate driver discount code --> driver payment --> confirm the order

API 1-1: (Batch) Product synchronization And Price update #

Description

The function of this API is to batch synchronize the product information of a gas station including their price. If you prefer to update one product at a time, you can use the single one.

RMS System should call this API in these scene：

• 1.At the first time a gas station join with 99

In this scene, the gas station manager or RMS team will do some initialization config, so that this gas station can join

99. At this time, RMS should synchronize all the product information of this gas station to 99.

• 2.When there are some products need to be updated

Anytime the gas station manager adds a product, updates a product information or changes it's price, RMS should call this API and transfer the updated information to 99.

URL: /open/rms/productSync

Request Method:POST

Content-Type: application/json

Request Traffic Limit: <= 100 QPS (request per second)

Request Parameters #

The parameter products is of type array, and we allow a maximum of 500 product array elements for a single request

products Patameter of Request #

example:

{
  "requestId": "73546bcc-dde9-4859-9e5d-05f3d8b0cc81",
  "gasStationID": "12345678000100",
  "timestamp": 1678923421,
  "products": [
    {
      "productCode": "123",
      "productDescription": "DIESEL",
      "productType": "Diesel S500",
      "fuel": true,
      "price": 10.02,
      "status": "ATIVO",
      "barcode": "112233",
      "ncm": "7766",
      "anp": "30303030"
    },
    {
      "productCode": "123",
      "productDescription": "DIESEL",
      "productType": "Diesel S500",
      "fuel": true,
      "price": 10.01,
      "status": "ATIVO",
      "barcode": "112233",
      "ncm": "7766",
      "anp": "30303030"
    }
  ]
}

CURL example:

you can use this piece code to generate authorization header in postman.

curl --location --request POST 'https://drvlab-test.didiglobal.com/open/rms/productSync' \
--header 'Authorization: DIDI-AUTH-SHA256|{"api_key":"b5e****************5f9206d0","nonce_string":"k547x6Dhm1xfuAtQpEdfg30fZ147nEcb","timestamp":"1701173474","signature":"502D0C33CD9CBFE45F40D80888E7503F48837CE3F3F779F9162387F56D8CBD57"}' \
--header 'Content-Type: application/json' \
--data-raw '{
    "requestId": "73546bcc-dde9-4859-9e5d-05f3d8b0cc81",
    "gasStationID": "T******",
    "timestamp": 1701143941,
    "products": [
        {
          "productCode": "123",
          "productDescription": "ETANOL",
          "productType": "ETANOL",
          "fuel": true,
          "price": 4.75,
          "status": "ATIVO",
          "barcode": "112233",
          "ncm": "7766",
          "anp": "30303030"
        },
        {
          "productCode": "124",
          "productDescription": "DIESEL",
          "productType": "DIESEL_S500_ADITIVADO",
          "fuel": true,
          "price": 10.0,
          "status": "INATIVO",
          "barcode": "112233",
          "ncm": "7766",
          "anp": "30303030"
        },
        {
        "productCode": "125",
        "productDescription": "Gasolina Aditivada",
        "productType": "GASOLINA_ADITIVADA",
        "fuel": true,
        "price": 3.75,
        "status": "ATIVO",
        "barcode": "112234",
        "ncm": "7765",
        "anp": "30303031"
        },
        {
        "productCode": "126",
        "productDescription": "Gasolina Aditivada",
        "productType": "GASOLINA_ADITIVADA",
        "fuel": true,
        "price": 3.85,
        "status": "INATIVO",
        "barcode": "112234",
        "ncm": "7765",
        "anp": "303"
        }
    ]
}'

Response Parameters #

Data Object Parameters #

Response Example #

Return Success (Status: 200) #

{
  "data": {
    "requestId": "3b146f42-180e-4bc1-960f-8efe907e9198"
  },
  "errmsg": "success",
  "trace_id": "0a0f163b623b0de5759f6f9e066c9f02"
}

Return Error (Status: 400) #

{
  "data": {
    "requestId": "3b146f42-180e-4bc1-960f-8efe907e9198"
  },
  "errmsg": "specified error message",
  "trace_id": "0a0f163b623b0de5759f6f9e066c9f02"
}

API 1-2: (Single) Product synchronization And Price update #

Description

The function of this API is to synchronize single product information of a gas station including their price. If you prefer to update many products at a time, you can use the batch one.

RMS System should call this api in these scene：

• 1.At the first time a gas station join with 99

In this scene, the gas station manager or RMS team will do some initialization config, so that this gas station can join

99. At this time, RMS should synchronize all the product info of this gas station to 99 with this API.

• 2.When there are some products need to be updated

Anytime the gas station manager adds a product, updates a product info or changes it's price, RMS should call this API and transfer the updated info to 99.

URL: /open/rms/singleProductSync

Request Method:POST

Content-Type: application/json

Request Traffic Limit: <= 100 QPS (request per second)

Request Parameters #

example:

{
  "requestId": "73546bcc-dde9-4859-9e5d-05f3d8b0cc81",
  "gasStationID": "12345678000100",
  "timestamp": 167895430,
  "productCode": "123",
  "productDescription": "DIESEL",
  "productType": "Diesel S500",
  "fuel": true,
  "price": 10.02,
  "status": "ATIVO",
  "barcode": "112233",
  "ncm": "7766",
  "anp": "30303030"
}

CURL example:

you can use this piece code to generate authorization header in postman.

curl --location --request POST 'https://drvlab-test.didiglobal.com/open/rms/singleProductSync' \
--header 'Authorization: DIDI-AUTH-SHA256|{"api_key":"b5e****************5f9206d0","nonce_string":"k547x6Dhm1xfuAtQpEdfg30fZ147nEcb","timestamp":"1701173474","signature":"502D0C33CD9CBFE45F40D80888E7503F48837CE3F3F779F9162387F56D8CBD57"}' \
--header 'Content-Type: application/json' \
--data-raw '{
    "requestId": "73546bcc-dde9-4859-9e5d-05f3d8b0cc81",
    "gasStationID": "T*****",
    "timestamp": 1701143941,
    "productCode": "123",
    "productDescription": "ETANOL",
    "productType": "ETANOL",
    "fuel": true,
    "price": 4.75,
    "status": "ATIVO",
    "barcode": "112233",
    "ncm": "7766",
    "anp": "30303030"
}'

Response Parameters #

Data Object Parameters #

Response Example #

Return Success (Status: 200) #

{
  "data": {
    "requestId": "3b146f42-180e-4bc1-960f-8efe907e9198"
  },
  "errmsg": "success",
  "trace_id": "0a0f163b623b0de5759f6f9e066c9f02"
}

Return Error (Status: 400) #

{
  "data": {
    "requestId": "3b146f42-180e-4bc1-960f-8efe907e9198"
  },
  "errmsg": "specified error message",
  "trace_id": "0a0f163b623b0de5759f6f9e066c9f02"
}

API 2: Discount code verification #

Description

This API is called when the customer finish the refuel process, he will come to the gas station oiler and show his discount code from 99, the oiler will input this code into RMS system, and RMS System should call this API to get how many discount the customer can get. We will generate orderId to you, and you can confirm or cancel order with this orderId.

URL:/open/rms/validateCode

Request Method:POST

Content-Type: application/json

Request Traffic Limit: <= 100 QPS (request per second)

Request Parameters #

Order Item Parameters #

example:

{
  "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851",
  "gasStationOrderId": "d290f1ee-6c54-4b01",
  "attendantName": "Barry",
  "discountCode": "TH2WBN",
  "totalOrderAmount": 1.98,
  "gasStationID": "12345678900000",
  "orderTime": 1699357865,
  "orderItemList": [
    {
      "productCode": "123456",
      "totalAmount": 1.98,
      "unitPrice": 0.16,
      "quantity": 12.356
    }
  ]
}

CURL example:

you can use this piece code to generate authorization header in postman.

curl --location --request POST 'https://drvlab-test.didiglobal.com/open/rms/validateCode' \
--header 'Authorization: DIDI-AUTH-SHA256|{"api_key":"b5e****************5f9206d0","nonce_string":"k547x6Dhm1xfuAtQpEdfg30fZ147nEcb","timestamp":"1701173474","signature":"502D0C33CD9CBFE45F40D80888E7503F48837CE3F3F779F9162387F56D8CBD57"}' \
--header 'Content-Type: application/json' \
--data-raw '{
    "requestId":"062194ed-2cb3-481c-b1dd-02dc7cf4097d",
    "gasStationOrderId": "481c-b1dd-02dc7cf4097b",
    "attendantName":"*******",
    "discountCode":"9****",
    "totalOrderAmount":10.08,
    "gasStationID":"T************",
    "orderTime":1688990617,
    "orderItemList":[
        {
            "productCode": "123",
            "totalAmount": 10.08 ,
            "quantity":2,
            "unitPrice":5.04
        }
    ]
}'

Response Parameters #

Data Object Parameters #

Order Item Response Parameters #

example:

Return Success (Status: 200) #

{
  "errmsg": "",
  "data": {
    "uuid": "7a4c2a05-2b2b-900d-818f-eb6b8f9daff4",
    "orderId": "7a4c2a05-2b2b-900d-818f-eb6b8f9daff4",
    "totalDiscountedOrderAmount": 269.5,
    "totalDiscount": 30,
    "totalStationDiscount": 30,
    "total99Discount": 0,
    "totalPartnerShipFee": 0,
    "orderItems": [
      {
        "uuid": "716f9887-4c0e-96b8-af40-e6f7634a7410",
        "productCode": "1",
        "discountAmount": 30,
        "stationDiscount": 30,
        "99Discount": 0,
        "partnerShipFee": 0
      }
    ]
  },
  "trace_id": "s58080b766d80edbbf2407c30eb9db02"
}

Return Error (Status: 400) #

{
  "data": {
    "orderId": "081894fd-2cb3-481c-b1dd-02dc7cf4055b",
    "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851"
  },
  "errmsg": "specified error message",
  "trace_id": "0a0f163b623b0de5759f6f9e066c9f02"
}

API 3: Confirm Order #

Description

After the driver completes their payment of the fuel order,RMS should call this api to synchronize the order info to 99.

URL:/open/rms/order/confirm

Request Method:POST

Content-Type:application/json

Request Traffic Limit: <= 100 QPS (request per second)

Request Parameters #

paymentMethod Item Parameters of Request #

example:

{
  "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
  "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851",
  "receipt": "https://www.sefaz.rs.gov.br/NFCE/NFCECOM.aspx",
  "orderTime": 1699357865,
  "paymentMethod": [
    {
      "type": "Carteiras digitais",
      "amount": 50.00
    },
    {
      "type": "Pix",
      "amount": 50.00
    }
  ]
}

CURL example:

you can use this piece code to generate authorization header in postman.

curl --location --request POST 'https://drvlab-test.didiglobal.com/open/rms/order/confirm' \
--header 'Authorization: DIDI-AUTH-SHA256|{"api_key":"b5e****************5f9206d0","nonce_string":"k547x6Dhm1xfuAtQpEdfg30fZ147nEcb","timestamp":"1701173474","signature":"502D0C33CD9CBFE45F40D80888E7503F48837CE3F3F779F9162387F56D8CBD57"}' \
--header 'Content-Type: application/json' \
--data-raw '{
    "requestId": "deeee-t5staecgs6z91r7jo-60aa5af964f58",
    "orderId": "o8yzmr63u91d7b5qq11-60aa5af965070",
    "orderTime": 1683787223,
    "receipt": "https://www.sefaz.rs.gov.br/NFCE/NFCECOM.aspx",
    "paymentMethod": [
      {
        "type": "Carteiras digitais",
        "amount": 50.00
      },
      {
        "type": "Pix",
        "amount": 50.00
      }
    ]
}'

Response Parameters #

Data Object Parameters #

example:

Return Success (Status: 200) #

{
  "data": {
    "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
    "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851"
  },
  "errmsg": "success",
  "trace_id ": "0a0f163b623b0de5759f6f9e066c9f02"
}

Return Error (Status: 400) #

{
  "data": {
    "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
    "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851"
  },
  "errmsg": "specified error message",
  "trace_id ": "0a0f163b623b0de5759f6f9e066c9f02"
}

Wrong example

API 2(Discount code verification) Return:

{
  "errmsg": "",
  "data": {
    "uuid": "f948d483-6b01-934a-87d9-f00ceabfbb50",
    "orderId": "f948d483-6b01-934a-87d9-f00ceabfbb50",
    "totalDiscountedOrderAmount": 100,
    "totalDiscount": 12,
    "orderItems": [
      {
        "uuid": "a24ed55e-a902-9768-bb72-0b6c70b53ad5",
        "productCode": "00001",
        "discountAmount": 12
      }
    ]
  },
  "trace_id": "0a0f270d665fe09799ef36690e12d302"
}

Wrong Confirm Order Request

{
  "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
  "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851",
  "receipt": "https://www.sefaz.rs.gov.br/NFCE/NFCECOM.aspx",
  "orderTime": 1699357865,
  "paymentMethod": [
    {
      "type": "Carteiras digitais",
      "amount": 50.01
    },
    {
      "type": "Pix",
      "amount": 50.00
    }
  ]
}

Because totalDiscountedOrderAmount in API 2 returns 100, the sum of the amounts in the paymentMethod array should be consistent with it. However, in this example, 50.01 + 50.00 = 100.01, which is not equal to 100, so we will return an error message. The error message is as follows:

{
  "errmsg": "O montante do pagamento é incoerente",
  "data": {
    "uuid": "cb1bd8de-09b1-9d26-8d72-0ce560b1abe0",
    "orderId": "cb1bd8de-09b1-9d26-8d72-0ce560b1abe0",
    "requestId": "1e2610a1-9336-40dd-92f5-5bedecdf8a7e"
  },
  "trace_id": "0a9fe884665fe01d50cfc59a137f1c02"
}

API 4: Cancel Order #

Description

This function is used for cancel the transaction. RMS System should call this API in these scene:

1. When the customer completed code verification but not complete the payment.
2. When the customer completed the payment, but he want to cancel the transaction.

URL:/open/rms/order/cancel

Request Method:POST

Content-Type:application/json

Request Traffic Limit: <= 100 QPS (request per second)

Request Parameters #

example:

{
  "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
  "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851",
  "receipt": "https://www.sefaz.rs.gov.br/NFCE/NFCECOM.aspx",
  "orderTime": 1683787223
}

CURL example:

you can use this piece code to generate authorization header in postman.

curl --location --request POST 'https://drvlab-test.didiglobal.com/open/rms/order/cancel' \
--header 'Authorization: DIDI-AUTH-SHA256|{"api_key":"b5e****************5f9206d0","nonce_string":"k547x6Dhm1xfuAtQpEdfg30fZ147nEcb","timestamp":"1701173474","signature":"502D0C33CD9CBFE45F40D80888E7503F48837CE3F3F779F9162387F56D8CBD57"}' \
--header 'Content-Type: application/json' \
--data-raw '{
    "orderId": "o8yzmr63u91d7b5qq11-60aa5af965070",
    "orderTime": 1683787223,
    "receipt": "https://www.sefaz.rs.gov.br/NFCE/NFCECOM.aspx"
}'

Response Parameters #

Data Object Parameters #

example:

Return Success (Status: 200) #

{
  "data": {
    "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
    "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851"
  },
  "errmsg": "success",
  "trace_id ": "0a0f163b623b0de5759f6f9e066c9f02"
}

Return Error (Status: 400) #

{
  "data": {
    "orderId": "3b146f42-180e-4bc1-960f-8efe907e9198",
    "requestId": "d290f1ee-6c54-4b01-90e6-d701748f0851"
  },
  "errmsg": "specified error message",
  "trace_id ": "0a0f163b623b0de5759f6f9e066c9f02"
}

API 5: Heartbeat #

Description

This function is used to detect the Availability between RMS and 99, you should request this api every 5 minutes, you don't need to be processed the error of this API

URL:/open/rms/heartbeat

Request Method:POST

Content-Type:application/json

Request Traffic Limit: <= 100 QPS (request per second)

Request Parameters #

example:

{
  "gasStationID": "T1404529600020"
}

CURL example:

you can use this piece code to generate authorization header in postman.

curl --location 'https://drvlab-test.didiglobal.com/open/rms/heartbeat' \
--header 'Authorization: DIDI-AUTH-SHA256|{"api_key":"b5e****************5f9206d0","nonce_string":"k547x6Dhm1xfuAtQpEdfg30fZ147nEcb","timestamp":"1701173474","signature":"502D0C33CD9CBFE45F40D80888E7503F48837CE3F3F779F9162387F56D8CBD57"}' \
--header 'Content-Type: application/json' \
--data '{
    "gasStationID": "T1404529600020"
}'

Response Parameters #

example:

Return Success (Status: 200) #

{
  "data": null,
  "errmsg": "success",
  "trace_id ": "0a0f163b623b0de5759f6f9e066c9f02"
}

Return Error (Status: 400) #

{
  "data": null,
  "errmsg": "specified error message",
  "trace_id ": "0a0f163b623b0de5759f6f9e066c9f02"
}

API 6: Get Product Info (From RMS, Not Necessary) #

Description

This function is used for getting all product information of the special gas station according to cnpj. This function should be supplied by RMS but not necessary.

URL:/open/rms/getProductInfo

Request Method:GET

Content-Type:application/json

Request Parameters #

example:

{
  "gasStationID": "12345678000100"
  "page": 1,
  "size": 10,
  "fuel": false
}

Response Parameters #

Data Object Parameters #

Products Parameter of Data Parameter #

example:

Return Success (Status: 200) #

{
  "errmsg": "success",
  "trace_id": "0a0f120f637304feb06e4cabb166e702",
  "data": {
    "gasStationID": "12345678000100",
    "count": 1000,
    "products": [
      {
        "productCode": "123",
        "productDescription": "DIESEL",
        "productType": "Diesel S500",
        "fuel": true,
        "price": 10.01,
        "status": "ATIVO",
        "barcode": "112233",
        "ncm": "7766",
        "anp": "30303030"
      },
      {
        "productCode": "123",
        "productDescription": "DIESEL",
        "productType": "Diesel S500",
        "fuel": true,
        "price": 10.01,
        "status": "ATIVO",
        "barcode": "112233",
        "ncm": "7766",
        "anp": "30303030"
      }
    ]
  }
}

Return Error (Status: 400) #

{
  "data": null,
  "errmsg": "specified error message",
  "trace_id": "0a0f163b623b0de5759f6f9e066c9f02"
}
